Гидравлический насос Haulotte 2505006610

Гидравлический насос Haulotte 2505006610

Casappa 799139PM

KP30.43-A8K9-LME/OC/OD/X-N-

Бренд

CASAPPA

Type of pump

gearpump

Number of elements

2

Type of flange

type A

Diameter of flange mounting holes D1

14.5 mm

Center distance of mounting holes flange C1

146 mm

Total length of pump L1

257 mm

Neck diameter D2

101.5 mm

Type of shaft

type D

Distance from flange to end L2

40.5 mm

Diameter of shaft D3

21.5 mm

Number of splines

13

Direction of rotation

clockwise

Position of suction port 1st element, only for pump type T POS-CO1

side

Type of connections suction port1st element, only for pump type T TY-Coa

type C

Thread type of connections suction 1st element

M12

Center distance between mounting holes C-CO1a

35.7 mm

Center distance between mounting holes C-CO2a

69.9 mm

Position of pressure port

side

Type of connections

type E

pressure port 2nd element, only for pump

type T TY-COd

Thread type pressure side of 2nd element TA-Pd

7/8 UNF

Flow control valve present

Yes

Biggest Thread type valve TA3

1 1/16 UNF

Second Thread type valve TA4

7/8 UNF

Material of the housing

metal

Вес (кг)

22.74
