Главная Пара New Holland 86025263
111 ₽
Главная Пара New Holland 86025263
Описание
Главная Пара NEW HOLLAND 86025263
86539514
219784
| Номер по каталогу |
Описание запчасти |
| 9707397 | HOUSING |
| 9672497 | STUD-STEEL Threaded 8Unc-2A 2-Ends, Dia-1.0in Lth-4.50in |
| 86505943 | PLUG, HEX 3/4NPTF |
| 163410 | PLUG - HexHead C/W O-RING, 1-1/16 - 12un Orb |
| 86030726 | COVER Weld Assy, BOTTOM PTO DROPBOX |
| 9706726 | CAPSCREW - FLANGE LOCK, USR 3/8in x 16 x 1in |
| 9672327 | SHAFT-OUTPUT, PTO DROPBOX ASSY |
| V48241 | GEAR, SPUR 43 Tooth, PTO DROPBOX ASSY |
| 17370 | Cup, Bearing |
| 529523 | CONE - BEARING Roller Taper Single, Id-1.75 Thk-0.99 |
| 9702542 | SHIM, 0.075 OUTPUT SHAFT |
| 9702538 | SHIM, 0.50 OUTPUT SHAFT |
| 9702539 | SHIM, 0.250 OUTPUT SHAFT |
| 9702541 | SHIM, 0.05 OUTPUT SHAFT |
| 9702535 | COVER - CAP, OUTPUT SHAFT, PTO DROPBOX |
| 9790555 | WASHER - STEEL Hrdn, Id-0.469 Od-0.750 Thk-0.095 |
| 280410 | CAPSCREW - HexHead, 0.44 x 1.00 Gr8 Pl |
| 16275 | Seal, Oil |
| 9702534 | COVER, CAP |
| 86028077 | SHIELD - MASTER, PTO DROP BOX Output (Red) |
| 280244 | CAPSCREW - HexHead Gr-5, 7/16 x 14 x 3/4 Pl |
| 9672326 | COUNTERSHAFT, PTO DROPBOX ASSY |
| 517511 | BEARING - CUP, RLR Tpr OD-4.125in Thk-0.9375in |
| 9672496 | BEARING-CONE, Sgl Taper Roller ID-44.450mm Thk-30.162mm |
| 9672499 | GASKET - Shim Stock Steel 0.005, PTO DROPBOX BOX |
| V48610 | GASKET- STEEL, Shim Stock, PTO BOX Thk-0.020 mil tol |
| 9672498 | GASKET - Shim Stock Steel 0.003, PTO DROPBOX BOX |
| V48609 | GASKET, PTO BOX 0.01 |
| 9672486 | CAP - COUNTERSHAFT |
| 9702537 | CAP-BEARING, PTO DROPBOX |
| 9672438 | PLUG - HexHead, C/W O-Ring 7/16in -20unf-2A |
| V48242 | SHAFT-INPUT, PTO DROPBOX ASSY |
| V48240 | GEAR, SPUR 21 Tooth, PTO DROPBOX ASSY |
| 86508488 | SEAL - OIL Nitrile, Id-2.375 Od-3.35 Thk-0.438in |
| 9672485 | BEARING - CAP PTO INPUT |
| 9700670 | YOKE, END 1550 SERIES |
| 86050252 | WASHER 1.312 x 2.250 x 0.12 Pl |
| 165916 | NUT, SLOT HEX 1.25 18unef |
| 86523957 | PIN - COTTER SPLIT, 5/32 x 2in |
| 9672320 | PLUG - EXPANSION CONCAVE SPECIAL 1/2in |
| 9701035 | SHIELD, PTO DROP BOX |
| 9701033 | COVER - TOP, PTO DROPBOX |
| 80463 | NUT, LOCK NYLON 0.38NC GR5 PL |
| 9672414 | WASHER, 13.00x24.00x0.95 HDN BI |
| 50213 | Plug, Pipe, Hex Soc |
| Номер по каталогу |
Описание запчасти |
| 86002003 | CLUTCH - HYDRAULIC ASSY, 5.25 - 12 Plate |
| 86002004 | DRUM, ADAPTER |
| 86002006 | CLUTCH, PACK |
| 9703182 | CLUTCH SHAFT |
| V48531 | PLATE - SEPARATOR, PTO CLUTCH Assy L4wd |
| 9672475 | RING-SNAP, EXTERNAL Id-55.63mm Thk-1.32mm |
| V55426 | PIN |
| 86012300 | O-RING NITRILE, Id-5.7in Thk-0.125i |
| 9703184 | PISTON HOUSING |
| 9672495 | SEAL - RING Hook Type, 5.25 PTO CLUTCH PISTON Assy |
| 9672476 | SEAL - RING Polyacrylate, PTO CLUTCH PISTON Assy |
| 9703183 | PISTON CLUTCH |
| 9672477 | RING - SNAP INTERNAL |
| 9672482 | RING |
| 9672483 | RING, SNAP |
| 86002005 | CLUTCH HUB |
| 9703186 | HUB |
| 9672479 | PLATE |
| 9672480 | RING |
| 9672481 | RING |
| 9702491 | CLUTCH, PLAT |
| 9672478 | PLATE - CLUTCH, (steel) |
| 127819 | Ring, Snap, Ext, 2.375" |
| 9703192 | ROLLER BEARING |
| 9703193 | SHAFT |
| 9703195 | SEAL RING |
| 9702038 | HUB,BRAKE |
| 9702491 | CLUTCH, PLAT |
| 9672484 | PLATE, CLUTCH |
| 9703188 | PLATE |
| 9703191 | WASHER |
| 9703190 | SPACER |
| 9703187 | BRAKE HUB |
| 9673111 | SPRING PIN |
