Фара задняя Manitou 661973
223766 223767 234929 927223 927224
Shape of the rear light
other
Total length (L1) (mm)
350
Length of the housing surrounding the lens (L2) (mm)
350
Total height (H1) (mm)
128
Height of the housing surrounding the lens (H2) (mm)
128
Total width (W1) (mm)
85
Width of the housing surrounding the lens (W2) (mm)
85
Bracket present
NO
Position of attachment
built-up
Horizontal mounting
YES
Vertical mounting
NO
Number of mounts
2
Type of mounting
bolt
External thread size
M8
Metric pitch of the external thread (mm)
1.25
Right thread/left thread of the external thread
right hand thread
Longest centre distance of the mounting holes (C1) (mm)
152
Minimum voltage (U1) (V)
12
Maximum voltage (U2) (V)
24
Number of connectors
1
Number of pins in the connector
6
Rear light present
YES
Stoplight present
YES
Indicator light present
YES
Reversing light present
YES
Fog light present
YES
Licenseplate light present
NO
Reflector present
NO
Triangular reflector
NO
Right side/left side/both sides mountable
left side
Bulbs included
NO
Replaceable lens
YES
Material of the lens
plastic
Type of technology
incandescent
IP value (water- and dustproof)
67
Вес (кг): 1,17
