Стартер Kalmar 924015.1334
111 ₽
Стартер Kalmar 924015.1334
Характеристики
| Вес16,95 кг |
Описание
Стартер KALMAR 924015.1334
9240151334
Starter type
starter
Type of head
P
Voltage (V)
24
Power (kW)
7.5
Neck diameter D1 (mm)
92
Pinion diameter D2 (mm)
55
Number of teeth
11
Direction of rotation of the pinion
CW
Overall length of the starter L (mm)
415
Distance between pinion and flange L2 (mm)
47
Distance drive cover (mm)
55
Number of holes
3
Position of fixation holes
45-05-25
Distances between fixation holes
126-126-126
Diameter mounting holes D3 (mm)
16.5
Oil sealed
YES
Вес (кг): 16,95
Технические характеристики Стартер Kalmar 924015.1334
Основные
| Вес | 16,95 кг |
|---|
