Гидравлический насос Bosch 1517222770
AZPF-11-016RNZXXPXXXX21-S0164
Type of pump
gearpump
Number of elements
1
Type of flange
type L
Diameter of flange mounting holes D1 (mm)
9
Center distance of mounting holes flange C1 (mm)
60.2
Center distance of mounting holes flange C2 (mm)
113
Total length of pump L1 (mm)
128
Neck diameter D2 (mm)
37.5
Type of shaft
type B
Diameter of shaft D3 (mm)
17
Key (way) width W (mm)
8
Direction of rotation
clockwise
Position of suction port 1st element, only for pump type T POS-CO1
front
Type of connections suction port1st element, only for pump type T TY-COa
type F
Position of pressure 1st element, only for pump type T POS-CO2
side
Type of connections pressure 1st element, only for pump type T TY-COb
type E
Thread type pressure side of 1st element TA-Pb
M18
Flow control valve present
NO
Material of the housing
aluminium
Вес (кг): 4,7
