Гидравлический насос NEW HOLLAND 87743513

Гидравлический насос NEW HOLLAND 87743513

79914143

85826149

87362337

CASE 87743506 87362336

Hema HPX52017

Casappa 799137H0

799137HO

79914143

79914144

799137GY

799137J8

KP30.38-05S6-LMF/OD-M5-KSL/30

Casappa 799137J4

KP30.34-05S6-LMF/OD-M5-KSL/30

Type of pump

gearpump

Number of elements

2

Type of flange

type G

Diameter of flange mounting holes D1 (mm)

14.4

Center distance of mounting holes C1 (mm)

114.5

Total length of pump L1 (mm)

390

Neck diameter D2 (mm)

127

Type of shaft

type D

Distance from flange to end L2 (mm)

46

Diameter of shaft D3 (mm)

25

Number of splines

15

Direction of rotation

clockwise

Position of suction port 1st element, only for pump type T POS-CO1

side

Type of connections suction port1st element, only for pump type T TY-COa

type C

Thread type of connections suction 1st element

M12

Center distance between mounting holes C-CO1a (mm)

42.5

Center distance between mounting holes C-CO2a (mm)

78

Position of pressure 1st element, only for pump type T POS-CO2

side

Type of connections pressure 1st element, only for pump type T TY-COb

type E

Thread type pressure side of 1st element TA-Pb

1 1/16 UNF

Flow control valve present

YES

Biggest Thread type valve TA3

7/8 UNF

Second Thread type valve TA4

3/4 UNF

Material of the housing

metal

Вес (кг): 33
