Гидронасос Fermec 6109162M91
111 ₽
Гидронасос Fermec 6109162M91
Описание
FERMEC-TEREX HPX52034
6109162M91
Parker 7029121002
HEMA X1A50375037
David Brown 111505/111503/1C
FERMEC - TEREX 860 Loader, 960 TDL (160)
Альтернативный номер X1A50465036Q52A1H1B0X1BC
| Type of pump | gearpump |
|---|---|
| Number of elements | 2 |
| Type of flange | type G |
| Diameter of flange mounting holes D1 (mm) | 14.5 |
| Center distance of mounting holes C1 (mm) | 114.5 |
| Total length of pump L1 (mm) | 330 |
| Neck diameter D2 (mm) | 127 |
| Type of shaft | type D |
| Distance from flange to end L2 (mm) | 45.6 |
| Diameter of shaft D3 (mm) | 24.8 |
| Number of splines | 15 |
| Direction of rotation | clockwise |
| Position of suction port 1st element, only for pump type T POS-CO1 | side |
| Type of connections suction port1st element, only for pump type T TY-COa | type C |
| Thread type of connections suction 1st element | M12 |
| Center distance between mounting holes C-CO1a (mm) | 35.6 |
| Center distance between mounting holes C-CO2a (mm) | 69.8 |
| Position of pressure 1st element, only for pump type T POS-CO2 | side |
| Type of connections pressure 1st element, only for pump type T TY-COb | type C |
| Thread type of connection pressure port 1st element TA-COb | M10 |
| Center distance between mounting holes C-CO1b (mm) | 22.2 |
| Center distance between mounting holes C-CO2b (mm) | 47.6 |
| Position of pressure port 2nd element, only for pump type T POS-CO4 | side |
| Type of connections pressure port 2nd element, only for pump type T TY-COd | type C |
| Flow control valve present | NO |
| Material of the housing | metal |
Вес (кг): 28
