Гидронасос Kalmar 924334.0002
9243340002
Type of pump
plunger pump
Number of elements
1
Type of flange
type G
Center distance of mounting holes C1 (mm)
114.5
Total length of pump L1 (mm)
338
Neck diameter D2 (mm)
127
Type of shaft
type D
Distance from flange to end L2 (mm)
56.5
Diameter of shaft D3 (mm)
32
Number of splines
14
Direction of rotation
clockwise
Thread type of connections suction 1st element
1/2 UNC
Center distance between mounting holes C-CO1a (mm)
42.9
Center distance between mounting holes C-CO2a (mm)
77.8
Thread type of connection pressure port 1st element TA-COb
3/8 UNC
Center distance between mounting holes C-CO1b (mm)
26.2
Center distance between mounting holes C-CO2b (mm)
52.4
Flow control valve present
NO
Material of the housing
metal
Торговая марка: DANFOSS
Вес (кг): 42
Kalmar DRF450-65S5
