Гидронасос MATBRO 37791
Parker 5835B
5U1/41130MAT
2PR037C
GP-37791MAT
Type of pump
gearpump
Number of elements
1
Type of flange
type N
Diameter of flange mounting holes D1 (mm)
9
Thread type of mounting holes TA1
M8
Total length of pump L1 (mm)
194
Neck diameter D2 (mm)
95
Type of shaft
type G
Distance from flange to end L2 (mm)
51.5
Key (way) width W (mm)
5
Thread type (on shaft) TA2
M16
Direction of rotation
clockwise
Position of suction port 1st element, only for pump type T POS-CO1
side
Type of connections suction port1st element, only for pump type T TY-COa
type E
Thread type suction side of 1st element TA-Pa
1 BSP
Position of pressure 1st element, only for pump type T POS-CO2
rear
Type of connections pressure 1st element, only for pump type T TY-COb
type E
Thread type pressure side of 1st element TA-Pb
3/4 BSP
Flow control valve present
NO
Material of the housing
metal
Вес (кг): 13,6
TS270, TR200, TS280
