Гидронасос SAUER-SUNSTRAND AFGP32L35945
99E-26 A32L 35945 AFGP32L 35945 20/905995 20905995 A32L35945 AFGP32L35945 20208400 20209800 1PLA54IA09R-HP7 550138810 38810 17665090
20/208400 20/209800 20/203200 20203200
JCB loader tm200
Type of pump
gearpump
Number of elements
1
Type of flange
type A
Diameter of flange mounting holes D1 (mm)
14.3
Center distance of mounting holes C1 (mm)
146
Total length of pump L1 (mm)
223
Neck diameter D2 (mm)
101.5
Type of shaft
type G
Distance from flange to end L2 (mm)
47
Diameter of shaft D3 (mm)
22.5
Key (way) width W (mm)
4
Thread type (on shaft) TA2
9/16 UNF
Direction of rotation
counter clockwise
Position of suction port 1st element, only for pump type T POS-CO1
side
Type of connections suction port1st element, only for pump type T TY-COa
type E
Thread type suction side of 1st element TA-Pa
1 BSP
Position of pressure 1st element, only for pump type T POS-CO2
side
Type of connections pressure 1st element, only for pump type T TY-COb
type E
Thread type pressure side of 1st element TA-Pb
3/4 BSP
Flow control valve present
NO
Material of the housing
aluminium
Вес (кг): 8,48
