Гидронасос Toyota CFY62B42.7ATCP1A7

Гидронасос Toyota CFY62B42.7ATCP1A7

CFY62B42-7ATCP1A7

CFY62B427ATCP1A7

SMD620B427L500

Type of pump

gearpump

Number of elements

2

Type of flange

type B

Center distance of mounting holes C1 (mm)

147

Total length of pump L1 (mm)

266

Neck diameter D2 (mm)

101

Type of shaft

type D

Distance from flange to end L2 (mm)

52

Diameter of shaft D3 (mm)

21.7

Number of splines

13

Direction of rotation

counterclockwise

Position of suction port 1st element, only for pump type T POS-CO1

side

Type of connections suction port1st element, only for pump type T TY-COa

type C

Thread type of connections suction 1st element

M10

Center distance between mounting holes C-CO1a (mm)

30

Center distance between mounting holes C-CO2a (mm)

57

Position of pressure 1st element, only for pump type T POS-CO2

side

Type of connections pressure 1st element, only for pump type T TY-COb

type C

Thread type of connection pressure port 1st element TA-COb

M10

Center distance between mounting holes C-CO1b (mm)

25

Center distance between mounting holes C-CO2b (mm)

52

Position of pressure port 2nd element, only for pump type T POS-CO4

side

Type of connections pressure port 2nd element, only for pump type T TY-COd

type E

Thread type pressure side of 2nd element TA-Pd

3/4 UNF

Flow control valve present

NO

Material of the housing

aluminium and metal

Вес (кг): 9,95
