Гидронасос PARKER 5U2/40095KOM
5U240095KOM
Type of pump
gearpump
Number of elements
2
Type of flange
type B
Center distance of mounting holes C1 (mm)
146
Total length of pump L1 (mm)
283
Neck diameter D2 (mm)
101.6
Type of shaft
type D
Distance from flange to end L2 (mm)
42
Diameter of shaft D3 (mm)
22.32
Number of splines
13
Direction of rotation
counter clockwise
Position of suction port 1st element, only for pump type T POS-CO1
side
Type of connections suction port1st element, only for pump type T TY-COa
type C
Thread type of connections suction 1st element
M12
Center distance between mounting holes C-CO1a (mm)
35.7
Center distance between mounting holes C-CO2a (mm)
69.85
Position of pressure 1st element, only for pump type T POS-CO2
side
Type of connections pressure 1st element, only for pump type T TY-COb
type C
Thread type of connection pressure port 1st element TA-COb
M10
Center distance between mounting holes C-CO1b (mm)
26.2
Center distance between mounting holes C-CO2b (mm)
52.4
Position of suction port 2nd element, only for pump type T POS-CO3
side
Type of connections suction port 2nd element, only for pump type T TY-COc
type E
Thread type suction side of 2nd element TA-Pc
1 1/16 UNF
Position of pressure port 2nd element, only for pump type T POS-CO4
side
Type of connections pressure port 2nd element, only for pump type T TY-COd
type E
Thread type pressure side of 2nd element TA-Pd
7/8 UNF
Flow control valve present
NO
Material of the housing
aluminium
Торговая марка: PARKER
Вес (кг): 12,33
